电磁继电器触点熔焊特性的研究综述

doi:10.16628/j.cnki.2095-8188.2025.11.001

摘要/Abstract

摘要：

电磁继电器作为电气系统的关键元件,其触点熔焊失效严重威胁系统的可靠性与稳定运行。基于对近年来研究文献的系统梳理,深入阐述触点熔焊现象的具体表现,综合分析影响熔焊特性的关键因素,探讨熔焊失效的内在机理。这些研究为优化继电器触点设计、提升产品抗熔焊能力和整体可靠性提供了重要的理论依据。面向未来,进一步探索新型触点材料,深入研究环境因素影响机制,是推动电磁继电器实现更高可靠性和更长使用寿命的关键方向。

关键词: 电磁继电器, 触点熔焊特性, 失效机理, 触点材料

Abstract:

As a key component of the electrical system,the contact welding failure of electromagnetic relays seriously threatens the reliability and stable operation of the system.Based on the systematic combing of research literature in recent years,the specific performance of contact welding is elaborated on, the key factors affecting the welding characteristics are comprehensively analyzed,and the intrinsic mechanism of welding failure is explored. An important theoretical basis is provided for optimizing the design of relay contacts, improving the anti-melt welding capability and overall reliability of the products.Looking to the future,the further exploration of new contact materials and the in-depth exploration of the influence mechanism of environmental factors are the key directions to promote electromagnetic relays to achieve higher reliability and longer service life.

Key words: electromagnetic relays, contaet welding characteristics, failure mechanism, contact material

中图分类号:

TM581

吴康, 王召斌, 谭力. 电磁继电器触点熔焊特性的研究综述[J]. 电器与能效管理技术, 2025, 0(11): 1-8.

WU Kang, WANG Zhaobin, TAN Li. Review on Research of Electromagnetic Relays Contact Welding Characteristics[J]. LOW VOLTAGE APPARATUS, 2025, 0(11): 1-8.

图/表 5

参考文献 33
