电器与能效管理技术 ›› 2021, Vol. 0 ›› Issue (2): 8-13.doi: 10.16628/j.cnki.2095-8188.2021.02.002

• 研究与分析 • 上一篇    下一篇

从专利浅述塑料外壳式断路器静触头导电回路技术

全嘉青

  1. 上海良信电器股份有限公司, 上海 201315
  • 收稿日期:2020-12-10 出版日期:2021-02-28 发布日期:2021-03-25
  • 作者简介:全嘉青(1977—),男,高级工程师,主要从事低压电器产品专利分析工作。

Discussion on Static Conductor Technology of MCCB from Patent

QUAN Jiaqing

  1. Shanghai Liangxin Electrical Co.,Ltd.,Shanghai 201315,China
  • Received:2020-12-10 Online:2021-02-28 Published:2021-03-25

摘要:

静触头导电回路对塑料外壳式断路器的性能起着重要的作用。列举了典型的塑料外壳式断路器静触头导电回路专利,并进行了分析,提出了一种新的静触头导电回路技术方案,希望能给研发人员提供参考。

关键词: 专利, 塑料外壳式断路器, 静触头导电回路, 电弧电压

Abstract:

The static conductor plays an important role in the performance of MCCB.This paper lists the typical patents of the static conductor of MCCB and did a brief analysis.In addition,a new technical scheme of static conductor was proposed,which can provide reference for the researchers.

Key words: patent, molded case circuit breaker(MCCB), static conductor, arc voltage
