DC Voltage Stabilization Control Strategy of Converter Under Unbalanced Grid Voltage

doi:10.16628/j.cnki.2095-8188.2023.02.013

Abstract

Abstract:

Under the condition of unbalanced grid voltage,the DC bus voltage will occur the second harmonic wave when the converter works in the voltage stabilizing mode.In order to solve this problem,the mechanism of DC bus voltage second harmonic wave during voltage stabilization operation of converter under unbalanced power grid voltage is analyzed.The DC voltage stabilization control strategy based on the proportional integral resonance (PIR) controller is proposed.On the basis of the original DC voltage stabilization control strategy,the secondary proportional resonance (PR) control is added to solve the problem that the current technology can not completely avoid the second harmonic wave of the DC bus voltage.It is not necessary to separate the positive and negative sequence of the current and obtain the current command through complex calculation.Finally,the effectiveness of the proposed control strategy is verified by simulation and experiment.

Key words: unbalanced grid voltage, second harmonic wave, DC voltage control, secondary PR control

CLC Number:

TM46

LIU Chongyang, WEI Yalong, LIU Gang, FAN Shuhao, QI Zhao. DC Voltage Stabilization Control Strategy of Converter Under Unbalanced Grid Voltage[J]. LOW VOLTAGE APPARATUS, 2023, 0(2): 68-73.

Figures/Tables 10

References 13

[1]	王成山, 李微, 王议锋, 等. 直流微电网母线电压波动分类及抑制方法综述[J]. 中国电机工程学报, 2017, 37(1):84-97.
[2]	周小平, 罗安, 陈燕东, 等. 直流微电网中双向储能变换器的二次纹波电流抑制与不均衡控制策略[J]. 电网技术, 2016, 40(9):2682-2688.
[3]	许阔, 王婉君, 贾利虎, 等. 混合微电网交流不对称故障对直流系统的影响[J]. 中国电机工程学报, 2018, 38(15):4429-4437,4643.
[4]	耿强, 夏长亮, 阎彦, 等. 电网电压不平衡情况下PWM 整流器恒频直接功率控制[J]. 中国电机工程学报, 2010, 30(36):79-85.
[5]	年珩, 程鹏. 电网电压不平衡时PWM整流器的谐振直接功率控制策略[J]. 电工技术学报, 2013, 28(11):86-94.
[6]	朱永强, 刘康, 张泉, 等. 混合微电网交流侧故障传播机理及抑制方法[J]. 电机与控制学报, 2020, 24(4):1-11.
[7]	刘迪, 杨海涛, 杨为, 等. 电网电压不平衡时 PWM 整流器脉动控制策略研究[J]. 电器与能效管理技术, 2019(10):8-12,16.
[8]	伞国成, 漆汉宏, 魏艳君, 等. 基于复功率的电网电压不平衡条件下并网逆变器控制策略[J]. 电工技术学报, 2017, 32(8):229-236.
[9]	林永朋, 陶顺, 肖湘宁. 电压不平衡条件下并网逆变器的直流电压控制[J]. 电网技术, 2015, 39(6):1643-1649.
[10]	SONG H S, NAM K. Dual current control scheme for PWM converter under unbalanced input voltage conditions[J]. IEEE Transactions on Industrial Electronics, 1999, 46(5):953-959. doi: 10.1109/41.793344
[11]	姜卫东, 吴志清, 佘阳阳, 等. 电网不平衡时抑制有功功率二次波动的并网逆变器控制策略[J]. 电力系统自动化, 2014, 38(15):106-111.
[12]	张伟, 桂在毅, 王沛东, 等. T型三电平逆变器内管开路故障的中点电位平衡研究[J]. 电器与能效管理技术, 2019(16):22-27.
[13]	侯蕊欣, 朱学洲, 胡道玖. 基于非连续脉宽调制的T型三电平容错控制[J]. 电器与能效管理技术, 2020(3):63-69.
