Optimal Control Method of Charging Station with Energy Storage System Considering Dynamic Safety Margin of Second-Use Batteries

doi:10.16628/j.cnki.2095-8188.2020.07.006

Abstract

Abstract:

In order to meet the demand of echelon utilization brought by large-scale decommissioning of power battery in the near future,an optimal control method according to the battery health assessment model in the whole life cycle in the application scenario of charging station with energy storage system was proposed.With the optimal control method,the output power of echelon energy storage system was limited while the cycle life was effectively extended.The feasibility and effectiveness of the model was proved by the example analysis.

Key words: second-use batteries, dynamic safety margin, charging station with ESS, energy optimization

CLC Number:

TM631

XI Peifeng. Optimal Control Method of Charging Station with Energy Storage System Considering Dynamic Safety Margin of Second-Use Batteries[J]. LOW VOLTAGE APPARATUS, 2020, 592(7): 36-41.

Figures/Tables 8

References 25
