Research Status and Trends of Key Technologies for Large Scale Wind/PV Hybrid Hydrogen Production and Storage System

doi:10.16628/j.cnki.2095-8188.2024.04.001

Abstract

Abstract:

The development of large-scale wind/PV hybrid hydrogen production and storage systems is of great and far-reaching significance for promoting China's energy strategic transformation, achieving energy conservation and emission reduction and developing high-quality new energy. However, the current research review on wind/PV hydrogen production is mainly focused on hydrogen production technology itself. There is still a lack of systematic review from multiple perspectives, including core equipment, operational control, safety protection and so on. Firstly,the development status of large-scale wind/PV hybrid hydrogen production technology at home and abroad was summarized. Then, from the perspective of key technological development, including the structure, core equipment, operation control, protection methods and safety monitoring of the wind/PV hybrid hydrogen production and storage system were analyzed and summarized. Finally, the future development trends and prospects of large-scale wind/PV hybrid hydrogen production and storage systems were predicted.

Key words: wind/PV hybrid hydrogen production and storage system, key equipment, opertaional control, protection method, security monitoring

CLC Number:

TM61

XING Xiaowen, MU Shujun, FAN Yujian, SUN Xun, ZHOU Yipeng. Research Status and Trends of Key Technologies for Large Scale Wind/PV Hybrid Hydrogen Production and Storage System[J]. LOW VOLTAGE APPARATUS, 2024, 0(4): 1-12.

Figures/Tables 7

References 80
