Research on Multi-Station Integration Planning and Arrangement Scheme

doi:10.16628/j.cnki.2095-8188.2023.06.008

Abstract

Abstract:

As an important element and a new type of infrastructure in the energy Internet, the multi-Station integration system will play an important role in the deep integration of energy and information in the future. An in-depth study was conducted on the planning and layout of the multi station fusion system, and a multi Station fusion system site selection and capacity optimization scheme based on the minimum cost of multi-dimensional load distance was proposed. Based on the specific situation of Hunan power grid, analysis was conducted and suggestions for the construction of the multi station fusion system in Hunan were given.

Key words: multi-station integration, group mode, multi-dimensional load distance, station planning

CLC Number:

TM715

LI Xiaoyun, LUO Zhongda, DING Xinyao, SUN Zhiyun, LU Xiaolong, TANG Ping, XU Yanfen, TANG Lisong. Research on Multi-Station Integration Planning and Arrangement Scheme[J]. LOW VOLTAGE APPARATUS, 2023, 0(6): 51-57.

Figures/Tables 4

References 17
